Incoloy 800/ 800h/ 800ht werkstoff nr. 1.4876 / 1.4958 / 1.4859 Tubes Manufacturer & Exporter.

Our Manufacturing organization has emerged for assembling Stainless Steel Incloy Welded Tube . The organization takes into account the corner markets of all the developing segments such as oil and gas. We, at Kobs India offer an extensive variety and known as SS Tube and Suppliers manufactured out of premium steel and is accessible in changing determinations with respect to measurement, material evaluation and diverse fitting closures.

With our expertise in the respective domain, we are involved in providing optimum quality range of SS Tube. Fabricated in strict tandem with the international quality standards, these pipes are appreciated for their durability, sturdy construction and application specific design. Our range caters to the requirements of various industries like construction, automobile and other engineering. We also have expertise in exporting capillary tubes, surgical pipes and other all industrials tubes, bars, pipes, sheet and plate in different materials such as stainless steel, aluminum, nickel, titanium, and carbon alloy with all customers on-demand grades.

Standards Specification:

Range : ½”Inch and 24”Inch

Outer Diameter : 1/8" NPS to 12" NPS

Thickness : 0.6 mm to 12.7 mm

Schedules : SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS.

Length : Single Random, Double Random & Cut Length

Specifications : ASTM A312 / ASTM SA312

Types : Round, Square, Rectangle, Hydraulic, Honed Tubes

End : Plain End, Beveled End



Material & Grade :

Incoloy :
Grade: Incoloy 800, Incoloy 800H, Incoloy 800HT

Chemical Composition

Incoloy 800 800H 800HT
Ni 30-35 30-35 30-35
Fe 39.5 min 39.5 min 39.5 min
Cr 19-23 19-23 19-23
Cu 0.75 max 0.75 max 0.75 max
Ti 0.15-0.60 0.15-0.60 0.25-0.60
Al 0.15-0.60 0.15-0.60 0.85-1.20
C 0.1 max 0.05-0.1 0.06-0.1
Mn 1.5 max 1.5 max 1.5 max
S 0.015 max 0.015 max 0.015 max
Si 1.0 max 1.0 max 1.0 max

Mechanical Properties

Density 7.94 g/cm3
Melting Point 1385 °C (2525 °F)
Tensile Strength Psi – 75,000 , MPa – 520
Yield Strength (0.2%Offset) Psi – 30,000 , MPa –205
Elongation 30 %

Product Features:

  • Durability
  • High strength
  • Effective functionality
  • Sturdy construction
  • Corrosion resistance
  • Dimensional accuracy

Manufacturing Process :

The process commences with the formation of welded mother tube on the tube mill from imported and tested prime quality stainless steel strips. The latest TIG multi electrode welding technique is employed for superior weld quality and 100% Fusion, with argon purging, No filler metal added.

Product Usage & Application :

  • Useful in Paper & Pulp Companies
  • Useful in High Pressure Applications
  • Useful in Oil and Gas Industry
  • Useful in Chemical Refinery
  • Useful in Pipeline
  • Useful in High Temperature Application
  • Useful in Water Pipe Line
  • Useful in Nuclear Power Plants
  • Useful in Food Processing and Dairy Industries
  • Useful in Boiler & Heat Exchangers

Other grades also available :

Stainless Steel :
Grade: 304, 304L, 304H, 309, 309S, 310, 310S, 316, 316H, 316L , 317, 317L, 321, 321H, 347, 347H, 904L
Duplex Steel:
Grade: 2205
Super Duplex Steel:
Grade: 2507 (UNS S32750)
Inconel :
Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718
Nickel :
Grade: Nickel 200, Nickel 201
Titanium :
Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11
Monel :
Grade: Monel 400, Monel K500, Monel R-405
Hastalloy :
Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X

Packing :

  • Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
  • We pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,
    • Shrink-wrapped
    • Carton boxes
    • Wooden pallets
    • Wooden boxes
    • Wooden crates

Why Choose Us :

  • You can get the perfect material according to your requirement at the least possible price.
  • We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
  • The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
  • e guarantee to give a response within 24hours(usually in the same hour)
  • You can get stock alternatives, mill deliveries with minimizing manufacturing time.
  • We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.

Tests we carry out (including both Destructive and Non-Destructive) :

  • Positive material recognition
  • Mechanical examining like tensile, Elongation and reduction of area.
  • Large-scale test
  • Chemical examination-Spectro analysis
  • Firmness test
  • Pitting protection test
  • Small tests
  • X-ray test
  • Impact analysis
  • Eddy current examining
  • Hydrostatic analysis
  • Prompt test
